Choose your product version
| Product description | Nominal wattage | Beam angle | Luminous flux | Dimmable |
|---|---|---|---|---|
| IP65 BULKHEAD 15W 830 WT OV | 15.00 W | 120 ° | 1200 lm | No |
| IP65 BULKHEAD 15W 830 WT R | 15.00 W | 120 ° | 1200 lm | No |
| IP65 BULKHEAD 15W 830 BK R | 15.00 W | 120 ° | 1200 lm | No |
| IP65 BULKHEAD 15W 830 BK OV | 15.00 W | 120 ° | 1200 lm | No |
| IP65 BULKHEAD 15W 840 WT OV | 15.00 W | 120 ° | 1350 lm | No |
| IP65 BULKHEAD 15W 840 WT R | 15.00 W | 120 ° | 1350 lm | No |
| IP65 BULKHEAD 15W 840 BK R | 15.00 W | 120 ° | 1350 lm | No |
| IP65 BULKHEAD 15W 840 BK OV | 15.00 W | 120 ° | 1350 lm | No |
| IP65 BULKHEAD 15W 865 BK R | 15.00 W | 120 ° | 1350 lm | No |
| IP65 BULKHEAD 15W 865 WT R | 15.00 W | 120 ° | 1350 lm | No |
| IP65 BULKHEAD 15W 865 WT OV | 15.00 W | 120 ° | 1350 lm | No |
| IP65 BULKHEAD 15W 865 BK OV | 15.00 W | 120 ° | 1350 lm | No |
| IP65 BULKHEAD 20W 830 BK R | 20.00 W | 120 ° | 1600 lm | No |
| IP65 BULKHEAD 20W 830 WT R | 20.00 W | 120 ° | 1600 lm | No |
| IP65 BULKHEAD 20W 830 WT OV | 20.00 W | 120 ° | 1600 lm | No |
| IP65 BULKHEAD 20W 830 BK OV | 20.00 W | 120 ° | 1600 lm | No |
| IP65 BULKHEAD 20W 840 BK R | 20.00 W | 120 ° | 1800 lm | No |
| IP65 BULKHEAD 20W 840 WT R | 20.00 W | 120 ° | 1800 lm | No |
| IP65 BULKHEAD 20W 840 WT OV | 20.00 W | 120 ° | 1800 lm | No |
| IP65 BULKHEAD 20W 840 BK OV | 20.00 W | 120 ° | 1800 lm | No |
| IP65 BULKHEAD 20W 865 BK R | 20.00 W | 120 ° | 1800 lm | No |
| IP65 BULKHEAD 20W 865 WT R | 20.00 W | 120 ° | 1800 lm | No |
| IP65 BULKHEAD 20W 865 WT OV | 20.00 W | 120 ° | 1800 lm | No |
| IP65 BULKHEAD 20W 865 BK OV | 20.00 W | 120 ° | 1800 lm | No |
| IP65 BULKHEAD 24W 830 BK R | 24.00 W | 120 ° | 2000 lm | No |
| IP65 BULKHEAD 24W 830 WT R | 24.00 W | 120 ° | 2000 lm | No |
| IP65 BULKHEAD 24W 840 WT R | 24.00 W | 120 ° | 2250 lm | No |
| IP65 BULKHEAD 24W 840 BK R | 24.00 W | 120 ° | 2250 lm | No |
| IP65 BULKHEAD 24W 865 WT R | 24.00 W | 120 ° | 2250 lm | No |
| IP65 BULKHEAD 24W 865 BK R | 24.00 W | 120 ° | 2250 lm | No |
| Nominal wattage | 15.00 W |
| Nominal voltage | 220…240 V |
| Mains frequency | 50…60 Hz |
| Power factor λ | > 0.90 |
| Protection class | II |
| Luminous flux | 1200 lm |
| Total luminous flux of contained light sources | 1350 lm |
| Luminous efficacy | 80 lm/W |
| Color temperature | 3000 K |
| Color rendering index Ra | > 80 |
| Beam angle | 120 ° |
| Length | 200.00 mm |
| Height | 45.00 mm |
| Width | 100.00 mm |
| Product weight | 157.00 g |
| Product color | White |
| Housing color | White |
| Body material | Plastic |
| Cover material | Polypropylene (PP) |
| Mercury content | 0.0 mg |
| Ambient temperature range | -20…+45 °C |
| Type of protection | IP65 |
| Dimmable | No |
| Mounting type | Surface |
| Application environment | Outdoor |
| Replaceable light source | No |
| Replaceable light source (EPREL) | Not replaceable |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | No |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4099854098796 | Folding box 1 |
100 mm x 48 mm x 205 mm | 211.00 g | 0.98 dm³ |
| 4099854098802 | Shipping box 20 |
510 mm x 220 mm x 225 mm | 4850.00 g | 25.25 dm³ |
| EAN | AU model number |
|---|---|
| 4099854098796 | LDVBHO15W830WH |
